ASRock DeskMini 310 Barebone
"The DeskMini 310 PC is really in a league almost of its own. It features the ability to run the latest Intel desktop CPUs, and in our case we had no trouble with it handling an i7-8700. It does take SO-DIMM memory, but other than that nothing is restricted to mobile versions as we see with NUCS.
On top of the obvious M.2 slot, the motherboard supports two SATA 2.5" SSDs and it even has an SD Card slot. Storage options are quite solid with this small PC.
The DeskMini 310 didn't throttle down, even when we ran an AVX load (AIDA64 Stability) for long periods of time. We were surprised by this, but we conclude its possible because of the vents all around the chassis. - TweakTown.com
Les hele testen her.
Supports Intel® 8th and 9th Core™ / Pentium® / Celeron® LGA1151 processors (Max. TDP 65W)
Dual DDR4 SO-DIMMs, up to 32GB
Triple Video outputs: DisplayPort, HDMI & D-Sub
1 x Ultra M.2 PCIe Gen3 x4 Slot
2 x 2.5" HDD/SSD Tray
1 x M.2 (2230) Wi-Fi Slot
USB 3.1 Gen1 Type-C port
Micro SD Card Reader
Smaller Size, Better Performance
Brand New DeskMini 310 supports Intel® 8th Gen Processors. Offering up to 72.6% CPU performance compare to previous generation.
The Small Big
DeskMini 310 features with under 2 liter size with desktop performance, offering big space to you.
Supports Intel® Box Fans
The world’s first Mini-STX build that supports standard Intel® box fans. The Mini Socket Technology Extended (Mini-STX) form factor adds the flexibility to support Intel® LGA CPU socket-based Intel® processors in the mini PC segment.
DeskMini 310 is the one of the most power-efficient in the PC market. It offers an idle power reduction of 33%!
DeskMini supports dual 7 & 9.5 mm height HDD room. There are two SATA3 headers on the opposite side of the motherboard, which supports 2 x 2.5” HDDs/SSDs.
Multi Display Outputs
This motherboard supports all three kinds of graphics D-Sub, HDMI and DisplayPort.
*Supports up to 2 displays simultaneously
A Type-C USB 3.1 Gen1 connector for fast charging and delivering up to 5Gbps data transfer rates.
Ultra M.2 + SATA 6Gb
H310M-STX motherboard features with PCIe Gen3 x4 M.2 SSD which is directly powered by the CPU, thus boasting 7% better performance. And it supports SATA 6Gb signal as well.
M.2 for PCIe & CNVi Wi-Fi module
H310M-STX adopts with M.2 2230 slot for Wireless + Bluetooth module.
In addition supporting latest CNVi - the integrated wireless IP portion of Intel® processors.
*Currently only support with 8th Gen Intel® Core™ processors system, CNVi module is not included.
Micro SD Card Reader
H310M-STX implement Micro SD Card Reader offering extra storage buffer or Linux based OS drive.
*Please refer to Micro SD Card support list
Intel® LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users!
